Adastra RM60, 100V zesilovač, 5 kanálový, 60W, USB/SD

100V line amplifiers with an integral mixer in a 2U rack-mountable housing. Featuring 5 input channels which include a balanced XLR microphone input with switchable phantom power and Vox override, 2 mic/line jack inputs and 2 RCA line inputs, of which one can be fed from the internal USB/SD card audio player. Bass & Treble EQ and Master volume control the overall output, which can power either low impedance or 100V line speakers. Generous features and versatility making a comprehensive control centre for commercial sound installations.

Technická data

Power supply: 110/240Vac, 50/60Hz (IEC)
DC power: 24Vdc (screw terminals)
Output : signal: 2 x RCA
Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line
Controls: Mic1, mic/line2+3, line4+5 (USB), bass, treble, master volume
Equalizer : bass: 100Hz Â10dB
Equalizer : treble: 10kHz Â10dB
Rear panel switches: Phantom, Vox, Mic/Line (2 + 3)
Phantom power: +20V (MIC 1 input)
THD: <1.0%
Dimensions: 433 x 320 x 89mm
Output power: 60Wrms
Outputs : speaker: 100V / 8 ohms / COM terminals
Speaker switching: N/A
Audio source: Integral USB/SD digital audio player
Weight: 5.98kg
